New Design Uv Laser Marking Machine Top Quality Co2 Fiber Laser Marking Machine Factory Inkjet Laser Printer
LCO-350 is mainly used in sapphire scribing, precision metal, camera module, PCB, VCM, FPC, SD card, QFN, BGA and
othermicroelectronics industries.
Features：
1. With automatic focusing function to avoid manual focusing positioning deviation;
2. The cutting software is easy to learn and comes with graphics editing functions, including inward shrinkage, outward expansion, size modification and adjustment, and graphic editing of cutting points;
3. With dynamic zoom function: according to the thickness of the customer's product, the number
of times of falling layer by layer can be realized when the board is divided, ensuring that the focal length is on the product
cutting;
4. With CCD automatic positioning, automatic calculation of expansion and contraction compensation function;
5. It has three-color light source, which can be adjusted to accurately identify the PCBA optical point and locate the position of the sub-board;
6. Equipped with a CCD that can read the QR code alone, to achieve MES data upload 1mm*1mm~6mm*6mm, and the code reading length is 19 digits;
7. The transmission height of the equipment can be adjusted by 900±50mm, and the track length is preferably 1000mm;
8. Comes with a laser chiller, equipped with a dust extraction system (automatic vacuum adsorption + laser dust
removal);
9. Equipment running accuracy ±0.005mm, CPK>1.33, sub-board accuracy ±0.025mm, processing capacity T≤1.6mm;
10. In line with the SMT anti-static standard, the product must be made of anti-static material within 30CM;
11. The safety door interlocking mechanism is configured, the safety door cannot be opened when the equipment is running, and the equipment cannot be operated after the door is opened. It is equipped with a leakage protector.
Specifications
| Item | LCO-350 |
| Laser Type | Green laser |
| Laser Power | 35W |
| Platform Range | 300*300mm double table |
| Adapt to Product Thickness (mm) | MAX1.5mm |
| Maximum Speed Of Platform | 1000m/s |
| Maximum Cutting Speed (mm/s) | ≥200 mm |
| Positioning Accuracy | ±0.005mm |
| Repeatability | ±0.005mm |
| Cutting Accuracy | ±0.025mm |
| Power | AC220V/50Hz, 3KW |
| Weight | 3200KG |
| Dimensions | L1600*W1300*H1800mm |
Efficient Technology Co.,Ltd provide a full SMT assembly line solutions, including SMT Production Line, SMT Pick and place machine, SMT Stencil Printer, SMT Inspection equipment, SMT Weling equipment, SMT Intelligent Storage System, SMT Automatic Insertion Machine, SMT Peripheral Equipment, SMT Feeders, SMT Nozzles, SMT Spare Parts etc any kind SMT machines you may need, please contact us for more information: WeChat: +8613714564591 Email: sales@efsmt.com
FAQ:
Q: What we can do for you?
A: One-stop SMT Solution Supplier; Reliable SMT Partner.
Q.What is your MOQ requirement for the machine?
A. 1 set moq requirement for the machine.
Q. This is the first i use this kind of machine, is it easy to operate?
A: Provide free training，There are also English manuals or instructional videos to show you how to use the machine.
Q: If the machine has any problem after we receive it, how can we do?
A: Our engineer will help to solve it first, and free parts send to you in machine warranty period.
Q: Do you provide any warranty for the machine?
A: Yes 1 year warranty will be provided for the machine.
Q: What is your payment terms?
A: 30% deposit in advance and 70% balance before shipment.
